INTEGRATE YOUR UR COBOTS

WITH GOCATOR 3D SNAPSHOT SENSORS

Integrating Gocator Snapshot Sensors With Universal Robots

Gocator® 3D snapshot sensors are certified for integration with UR3, UR5, UR10, and UR e-series robots—providing robot vision-guidance, quality control inspection, and automated assembly with smart pick-and-place.

  • Use structured light and a stereo camera design to capture high-density 3D point clouds of a part or feature from two different vantage points—all in a single “snapshot” scan.
  • Acquires 3D data AND analyzes the scan data to identify discrete parts and their location and orientation.
  • Ideal for robotic applications such as door panel gap & flush, roof/window insertion, and high accuracy pick-and-place.
Automation_Datasheets

Your robotics content bundle includes:

  • Successful Integration Case Study
  • Product features & benefits
  • Detailed product spec chart
  • Dimensional drawings and extras

The future is FactorySmart® inspection.

G3

Gocator 3D Snapshot Sensors

Gocator smart 3D snapshot sensors combine blue-LED structured light with built-in 3D measurement tools for specific object features. As opposed to lasers that are used to scan moving objects, snapshot sensors use a single snapshot scan to inspect targets with stop/stop motion.

Why Choose Gocator?

  • High Resolution and Repeatability for Precision Measurement
  • Large Fields of View for Scanning More of the Target with Fewer Sensors
  • Fast Scan Rates (Up to 10 kHz) for Inline Inspection at Production Speed
  • Best-in-class Performance on Challenging Surfaces Like Glass, Glue, Shiny Metals, Rubber
  • Available in a Wide Selection of Models that Suits Your Application

When your sensor is smart, your factory is smart.

Standard 3D sensors require a PC with 3rd party software in order to perform measurement and control. 3D smart sensors (like Gocator®) combine 3D scanning, measurement, and control decisions (sorting, pass/fail, alerts) inside a single factory pre-calibrated device.

  • All-in-one (scan, measure, control)
  • Web-enabled and factory connected
  • Small form factor with IP67-rated housing
  • No PLCs, external controllers, or 3rd party software required
  • High performance, low total cost of ownership

Gocator® is more than just a sensor. It’s a FactorySmart® sensor.

Scan_measure_control_comp
Emulator

Test Drive a Virtual 3D Smart Sensor

To learn more about Gocator®, we encourage you to get some hands-on experience by trying Emulator, a virtual 3D smart sensor that runs the full inspection software embedded in every Gocator––over any web browser, without a physical sensor.

  • Use Gocator web interface with easy point and click operations
  • Apply a wide range of measurements to real scan data
  • Work with 3D height map and 2D intensity data
  • Experiment with different scan targets and sensor models

You can either try it out right on our website using the online emulator, or download it to your computer and use it from your desktop. You also have the option of submitting a sample test request to get a fully customized emulator experience.

TRY GOCATOR EMULATOR

Let's talk smart 3D robot vision.
